Simrad ST90 User Manual

144
457420/A
•Master
InMastermode,theST90waitsforthedelaytimeaftertheexternaltriggersignal
hasbeensenttotheslavesbeforetransmittingtheping.Thisisoftenreferredtoas
apre-trigger.
Note
Thisdelaywillonlyworkwhenthesynchronizationissetupusingaserialport.
•Slave
InSlavemode,theST90waitsforthedelaytimeaftertheexternaltriggersignalhas
arrivedbeforetransmittingtheping.Thisisoftenreferredtoasapost-trigger.
8Fromthelistofportsavailable,selectSynchronizationPort.
Thisistheinterfaceportcurrentlyusedtotransmitorreceivesynchronizationsignals.
ItmustbeanRS-232serialport.Sincethesynchronizationfunctiononlyusesthe
RequestToSend(RTS)andClearToSend(CTS)signalsonaserialport,youcanuse
aportthatisalreadyusedforotherpurposes.Forthesamereason,youdonotneed
todeneanybaudrate.
9Atthebottomofthepage,selectApplytosaveyoursettings.
10ContinueyourworkintheInstallationdialogbox,orselectOKtocloseit.
Relatedtopics
Settinguptheinterfacestoperipheraldevices,page128
