Smart Optics mono Scan - Accessory Views

Operating Manual Audiology Scanners
Document version: 3.3 04-2020 21
4.3 Accessory views
Intended use
Object
holder*
Mounting of ear
impressions
Needles (top)
Neutral Left Right
Magnet (bottom)
3D calibration
object*
Required for 3D
calibration
Power
cable**
Scanner power supply
USB cable**
USB connection
Scanner – PC
As accessory:
* Available
** Not available
A
D
B
C
Key
A:
3D sensor/
Optical components
B:
Swivel axis
C:
Rotary axis
D:
Object holders
