Smart Optics mono Scan - Finishing and Exporting Work; Checking the Scan Results

Operating Manual Audiology Scanners
Document version: 3.3 04-2020 53
Renaming scans
 Mark the scan name you wish to change.
 Scan the barcode.
 aural Scan will ask if you wish to discard the current scan.
 Click on No.
 The scan will be kept, and the scan name changed.
9.8 Finishing and exporting work
Checking the scan results
Recommendation:
Adjust the Export-settings to your workflow:
 Export dialog
 Method
 FTP
 Save the scan data additionally in a separate directory
 Rotate the scans to check them:
 By 360° (space bar)
 Individually (mouse, icons).
The scan result is good if the ear impressions:
 Are fully scanned (without any holes)
 Do not contain any unnecessary components (excess lengths, base,
material residues).
Bad scan results can be caused by:
 Wrong view in the 3D viewer (e. g. points)
