Smart Optics mono Scan - 20 Quick Guide

Operating Manual Audiology Scanners
Document version: 3.3 04-2020 117
20 Quick guide
Workstation: table load-bearing capacity (kg) - scanner’s space
requirements (W×L×H mm, open):
mono Scan
duo
Scan
duo
Scan Touch
ds
Production
free
Stage
15 kg
16 kg
16 kg
20 kg
13 kg
300×367×350*
300×350×350*
300×350×350*
300×350×350*
186×293×348
* approximately
PC & operating system:
 Windows 10 (64-Bit)
 Quadcore CPU, i5
 8 GB RAM
 USB 2.0/3.0 Port
 Approx. 80 GB free hard drive space
 ≥ 1 GB RAM graphics card
Unpacking and connecting
 Remove the scanner and the accessories from the packaging.
 Remove the transport protection (pay attention to the needles).
TIP
Keep the packaging.
 Connect the power cable.
 Connect the USB cable:
Type B plug (square) to the scanner,
Type A plug (flat) to the PC.
 Switch on the scanner (LED switch on the front or toggle switch on the
rear).
 The scanner is ready for operation.
Installing aural Scan
 Copy the contents of the data carrier to the PC.
 Execute auralScan.exe.
 Follow the setup instructions.
 Start the software.
 Load the calibration data (folder SO-202…).
 Calibrate the axes.
 aural Scan is ready for operation.
