Operating Manual Audiology Scanners

Document version: 3.3 04-2020 8

Warnings

Warnings provide information on:

 Possible personal injuries

 Possible damages to objects

 Risk avoidance.

Warning levels

NOTICE

Material damages

CAUTION

Minor injuries

WARNING

Severe injuries

DANGER

Death or severe injuries
