Key Adjustments (Menus)
Chapter 4 Keys
Key Modify Clear
A simple button operation or a menu operation returns the
key settings to the initial status settings.
Press [Default Recall] at the lower left of the menu display,
turning it on, then press the corresponding VF button (VF1
to VF4) to return the key settings to their initial status.
For details of the initial status, see “Saving User-Defined
Settings” in Chapter 18 (Volume 2).
For the menu operation to return the key state to that set in
initial status, see “Returning to Default State in Function
Groupings” (page 60).
Blink Function
With the blink function, you can obtain the following
effects.
Key blink: The key is alternately inserted and deleted at
regular intervals. You can set the period of blinking,
and the proportion of each cycle for which the key is
inserted.
Edge blink: The key fill and key edge fill signals are
interchanged at regular intervals. You can set the
period of blinking, and the proportion of each cycle for
which the original state holds.
The blink settings are in the Transition menu for each key.
Using the blink function
For example, to make the required settings for key 1 on the
M/E-1 bank, use the following procedure.
1
In the M/E-1 >Key1 menu, select HF6 ‘Transition.’
The Transition menu appears.
2
In the <Blink> group, select [Key Blink] or [Edge
Blink] to set it on.
3
Set the blink parameters.
When key blink is selected
When edge blink is selected
Video Processing
You can adjust the luminance and hue of the selected key
fill signal.
For example, to apply video processing to the signal
selected on the M/E-1 bank key 1 fill bus, use the
following procedure.
1
In the M/E-1 >Key1 menu, select HF7 ‘Video
Process.’
The Video Process menu appears.
2
Press [Video Process], turning it on.
3
Adjust the following parameters.
To return adjustment values to their defaults
Press [Unity].
Knob Parameter Adjustment Setting values
1 Blink Rate Length of blink
cycle
1 to 100
2 Duty Proportion of
cycle for which
key inserted
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Blink Rate Length of blink
cycle
1 to 100
2 Duty Proportion of
cycle for which
original state
holds
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Video
Gain
Video gain –200.00 to
+200.00
2 Y Gain Luminance gain –200.00 to
+200.00
3 C Gain Chrominance
gain
–200.00 to
+200.00
4 Hue Delay Hue delay –180.00 to
+180.00
5Black
Level
Luminance black
level
–7.31 to
+109.59
Knob Parameter Adjustment Setting values
