144
Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
- MVS-8000X
- MVS-7000X
a) 0 when the system signal format is 1080P.
b) 1 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
c) 0 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
Basic Procedure for DME
Wipe Settings
You carry out DME wipe setting operations principally
using the DME Wipe menu for each bank.
This section describes the basic procedures for DME wipe
settings, taking the M/E-1 >DME Wipe menu as an
example.
For details of independent key transition DME wipe
settings, see “DME Wipe Settings for Independent Key
Transitions” (page 150).
For details of resizer DME wipe, see “Resizer DME Wipe
Setting” (page 152).
DME Wipe Settings Menu
Accessing the DME Wipe menu
To access the M/E-1 >DME Wipe menu, use either of the
following operations.
• In the menu control block, select the top menu selection
button [M/E 1], and press VF6 ‘DME Wipe.’
To select [M/E-4], a previous assignment in the Setup
menu is required.
• In the transition control block of the M/E-1 bank, press
the transition type selection button [DME] twice in rapid
succession.
DME Wipe Pattern Selection
Selecting a DME wipe pattern by a menu
operation
1
In the M/E-1 >DME Wipe menu, select HF1 ‘1ch’ for
one-channel mode, HF2 ‘2ch’ for two-channel mode
or HF3 ‘3ch’ for three-channel mode.
2
Select the desired DME wipe pattern group with one of
the following buttons.
• Slide/Squeeze: slide and squeeze
• Split/Door: split and door
• Flip Tumble: flip tumble
• Mirror/Sphere: mirror and sphere
• Character Trail: character trail
Applicable
block
Key to
which
DME
effects
are
applied
DME wipe
pattern for
background
Number of keys
to which DME
effects can be
applied
simultaneously
Other than
M/E-4
Keys 1
to 4
No DME
wipe used
2
One-channel
mode
1
Two - o r
three-
channel
mode
0
Keys 5
to 8
-
2
a)
M/E-4 Keys 1
to 4
No DME
wipe used
2
b)
One-channel
mode
1
c)
Two - o r
three-
channel
mode
0
Keys 5
to 8
-0
Key to
which
DME
effects are
applied
DME wipe pattern
for background
Number of keys to
which DME effects
can be applied
simultaneously
Keys 1 to 4 No DME wipe used 2
One-channel mode 1
Two- or three-
channel mode
0
Keys 5 to 8 -
2
a)
Notes
