550
Settings Relating to Signal Outputs (Output Menu)
Chapter 21 DME Setup (DME)
1
In the DME >Input menu, press [System Phase].
2
Set the following parameters.
Setting the TBC Window Center
Position
1
In the DME >Input menu, press [TBC Center].
The TBC Center menu appears.
The status area shows the TBC center position values
for DME1, DME2, and external input signals.
The TBC center position values for external input
signals are shown only when an MVE-9000 or MKS-
7470X/7471X is used.
2
Using any of the following methods, select the input
number for which you want to set the TBC center
position.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
3
In the <Video/Key> group (when MVE-9000 or
MKS-7470X/7471X is used), press the desired button,
and set the TBC center position to 0H, 0.5H, or 1H.
Settings Relating to
Signal Outputs (Output
Menu)
To make settings relating to DME output signals, display
the DME >Output menu.
You can select the signals output from the four monitor
output connectors.
To display the Output menu
In the Engineering Setup menu, select VF4 ‘DME’ and
HF3 ‘Output.’
The following functions are available here.
• Clip Adjust: Adjust the video clip levels of DME1 and
DME2 outputs.
(These settings are possible only when
the DME is an MVE-9000 or SDI-interfaced MVE-
8000A.)
• Monitor Output: Set the signals output from the four
monitor output connectors.
Adjusting the DME1 and DME2
Output Video Clip Levels
When the MVE-8000A/MVE-9000 is connected through
SDI interface, you can adjust both DME1 and DME2
output video clip levels.
Use the following procedure. (DME 1 is taken by way of
example.)
1
In the <DME1(Ch1-Ch4)> group of the DME >Output
menu, press [Clip Adjust], turning it on.
2
Set the following parameters.
To return the setting to the default value
In the DME >Output menu, press [Default].
Setting the Monitor Output
To set the signals output from the four monitor output
connectors, use the following procedure.
1
In the DME >Output menu, press [Monitor Output].
Knob Parameter Adjustment Setting values
1DME1
Phase
DME1 system
phase
adjustment
–32.00 to
+96.00
2DME2
Phase
DME2 system
phase
adjustment
–32.00 to
+96.00
Notes
Knob Parameter Adjustment Setting values
1 No Input number
selection
1 to 8
Knob Parameter Adjustment Setting values
1 White Clip White clip
adjustment
90.00 to 109.02
2 Dark Clip Dark clip
adjustment
−6.85 to +10.00
3 Chroma
Clip
Chroma clip
adjustment
90.00 to 113.17
To Next Page
