380
Registers
Chapter 13 Keyframe Effects
Registers
A register is an area of memory in a device which holds a
snapshot (see chapter 16), keyframe, macro (see chapter
13), and so on.
Keyframe effect registers
Dedicated effect registers
There are 99 dedicated registers for keyframe effects in
each region, numbered 1 to 99.
Shared user-programmable DME registers
In addition to the 99 DME registers for each region (i.e.
each channel), there are also shared registers for each
processor as shown in the following table. These are used
for user-programmable DME.
When operating with these shared registers, be sure to
select the appropriate regions depending on the number of
channels.
When recalling registers in the 200 range, select two
consecutive channels for the regions, as for example
[DME1] and [DME2]. Similarly, for registers in the 300
range, select three consecutive registers.
Registers for P-Bus Device regions
There are 250 registers for P-Bus and Device1 to Device12
in each region, numbered 1 to 250.
Work register
This is a temporary register used when editing keyframes.
When you recall an effect, it is read from the effect register
into the work register, and when you save, the contents of
the work register are written to the effect register.
Master timeline registers
There are 99 master timeline registers, numbered 1 to 99,
for each control panel. They store keyframe effect regions
and the register numbers saved in the regions.
Snapshot registers
These are registers for snapshots, and there are 99,
numbered 1 to 99 for each region.
Master snapshot registers
There are 99 master snapshot registers, numbered 1 to 99,
for each control panel. They store snapshot regions and the
register numbers saved in the regions.
Register
number
Register allocation
101 to 199 Shared register for one-channel effects
201 to 299 Shared register for two-channel effects
301 to 399 Shared register for three-channel effects
Notes
