418
Snapshot Operations in the Menus
Chapter 14 Snapshots
1
Press [Clip Event].
The Snapshot >Attribute >Clip Event menu appears.
2
In the <Frame Memory Select> group, press the
desired button.
On the left of the status area, the name and content of
the selected region (for example, USER1) are shown.
On the right, the content of the clip of the current frame
memory is shown.
3
Press [Clip Event], turning it on.
The clip event attribute is applied.
4
To select the clip of the current frame memory, press
[Set].
5
To play the clip as soon as it is recalled, press [Auto
Play], turning it on.
Snapshot Status Display
The Snapshot >Attribute menu displays the following
information.
Region name: The selected region name appears in the
upper part of the list.
Register number
Register name
Write-protected status: When the register is write-
protected, an “L” (for “lock”) appears.
Empty status: When the register is empty, an “E” (for
“empty”) appears.
Attribute settings: The attributes set for a register are
shown by the following character codes.
• When the cross-point hold is set
• When an effect dissolve is set
• When an auto transition is set
• When a GPI output is set
• When a clip event is set
Setting Key Snapshot Attributes
Applying key snapshot attributes
1
In the Snapshot menu, press VF5 ‘Key Snapshot’ and
HF1 ‘Attribute.’
The Snapshot >Key Snapshot >Attribute menu
appears.
The status area shows the region names, register
numbers, and whether the registers are locked or not.
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window. Selecting multiple regions is
also possible.
3
Press [OK].
The selected region name appears in the upper part of
the list.
4
Using any of the following methods, select the
register.
Displayed
character codes
Attributes set
A, B Cross-point hold is set for the A or B
background bus.
1, 2, 3, 4, 5, 6, 7, 8 Cross-point hold is set for key bus 1, 2,
3, 4, 5, 6, 7 or 8.
U1, U2 Cross-point hold is set for the utility 1 or
utility 2 bus.
D2 Cross-point hold is set for video bus
selected for 2nd DME channel.
FvFkBvBk Cross-point hold is set for all of the
DME front video bus, DME front key
bus, DME back video bus, and DME
back key bus.
Aux Cross-point hold is set for one of the
AUX buses.
Fm1, Fm2 Cross-point hold is set for one of the
frame memory 1 and 2 buses.
Ccr1, Ccr2 Cross-point hold is set for one of the
CCR 1 and 2 buses.
RTR Cross-point hold is set for the Router
region.
Displayed
character codes
Attributes set
Duration value The effect dissolve attribute is set, with
the displayed duration.
Displayed
character codes
Attributes set
T Auto transition is set.
Displayed
character codes
Attributes set
Port number GPI output is set for the port of the
displayed number.
Displayed
character codes
Attributes set
On Clip event is set.
Displayed
character codes
Attributes set
To Next Page
