156
Overview
Chapter 7 Frame Memory
Chapter
7
Frame Memory
Overview
Frame memory is a function whereby a frame of input
video can be frozen and written to memory, for further use
as material for editing.
You can also play recorded frame memory clips (movies).
Frame capacity
The frame memory board has two blocks of memory, and
the following table shows the maximum number of images
that can be written to each block. (Of the two, one is
reserved for storing frame memory clips.)
HD system:
(Without ancillary data)
(With ancillary data)
SD system:
(Without ancillary data)
(With ancillary data)
For details of operating procedures, see “Still Image
Operations” (page 158).
Types of image and terminology used
The following types of image are handled in frame
memory.
Freeze image: An input image that has been frozen, but
not saved to memory.
Still image: A freeze frame that has been saved to memory
as a file. Each file (still file) holds just one still image.
Frame memory clip: A clip consists of a sequence of still
images, which appears as a movie on playback. In this
manual this is also referred to simply as a “clip.” The
files (still files) constituting clips are referred to as a
“clip file.”
When the above distinctions are not being made, an image
is simply referred to as an “image.”
About extended clips
Of the two memory blocks for saving a clip, the clip saved
in the one which is not combined with a still image is
called an “extended clip.”
Video format Memory capacity
1080i/50 Approx. 1000 frames
1080i/59.94
1080PsF/23.976
1080PsF/24
1080PsF/25
1080PsF/29.97
1080PsF/50 Approx. 2300 frames
1080P/30
720P/50 Approx. 2300 frames
720P/59.94
Video format Memory capacity
1080i/50 Approx. 700 frames
1080i/59.94 Approx. 800 frames
1080i/60
1080PsF/23.976 Approx. 600 frames
1080PsF/24
1080PsF/25 Approx. 700 frames
1080PsF/29.97 Approx. 800 frames
1080PsF/30
720P/50 Approx. 1400 frames
720P/59.94 Approx. 1700 frames
Video format Memory capacity
480i/59.94 Approx. 5600 frames
576i/50 Approx. 4800 frames
Video format Memory capacity
480i/59.94 Approx. 4700 frames
576i/50 Approx. 3900 frames
Video format Memory capacity
