Super Mix Settings / Color Matte Settings
Chapter 3 Signal Selection and Transitions
Super Mix Settings
You can set the output levels of the current and new video
signals at the mid-point of the transition, in the range 0 to
100%.
This transition type is not available for an independent key
transition.
1 In the M/E or PGM/PST menu, select first VF7 ‘Misc,’
then HF1 ‘Transition.’
The Transition menu appears.
2 Select [Super Mix] in the <Transition Type> group.
3 Turn the knobs to adjust the output levels.
Color Matte Settings
You can specify the color matte by luminance, saturation,
and hue values.
Also, in place of a color matte you can use an image
selected on the utility 2 bus.
• This transition type is not available for an independent
key transition.
• In the multi-program mode, you can use a preset color
mix only when selecting the background for the next
transition.
One-stroke mode and one-time mode
• You can make a setting such that a preset color mix is
carried out in a single transition. This is called “one-
stroke mode.”
When the bus fixed mode is selected with a Setup menu
setting, a preset color mix is always carried out in the one-
stroke mode.
• You can also make a setting such that when a preset
color mix is completed, the next transition switches to
the previous transition type automatically. This is called
“one-time mode.”
Notes
Knob Parameter Adjustment Setting values
2 A Gain Background A
output level
0.00 to 100.00%
3 B Gain Background B
output level
0.00 to 100.00%
