Sony MVS-7000X - Assigning Functions to the Menu Control Block Top Menu and User Preference Buttons; Assigning Keys to the Cross-Point Control Block Key Delegation Buttons

497
Overall Control Panel Settings (Config Menu)
Chapter 19 Control Panel Setup (Panel)
4 Press [Inhibit].
Assigning Functions to the Menu
Control Block Top Menu and User
Preference Buttons
To these 41 buttons, you can freely assign a menu recall or
user preference button function.
1 In the Panel >Config menu, press [Link/Program
Button].
The Link/Program Button menu appears.
2 Press [Menu Panel].
The Menu Panel menu appears.
The left side of the status area shows the Top menu
selection buttons and user preference buttons, and the
right side shows a list of menus and actions to be
assigned.
3 Using any of the following methods, scroll the display.
• Press the arrow keys.
• Turn the knob.
4 In the button indications on the left, press the button
for the assignment.
5 Using any of the following methods, select the menu
or action to be assigned.
• Press directly on the right list.
• Press the arrow keys on the right list to scroll the
reverse video cursor.
• Turn the knob.
6 Press [Set] you confirm the setting.
This assigns the menu or action selected in the list to
the button.
To cancel an assignment, select the button, then press
[Clear].
To return all button assignments to the factory default
state, in the Menu Panel menu, press [Default].
Assigning Keys to the Cross-Point
Control Block Key Delegation
Buttons
1 In the Panel >Config menu, press [Link/Program
Button].
The Link/Program Button menu appears.
2 Press [CCP-9000 Key Deleg].
The CCP-9000 Key Delegation menu appears.
Four buttons appear for each of the M/E and P/P
banks.
3 Press the button to which you want to assign a key,
displaying it in reverse video.
4 Using any of the following methods, select the key you
want to assign from the Button Assign list.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
5 Press [Set].
Knob Parameter Adjustment Setting values
1 DME Ch DME channel
selection for
inhibiting
operations
1 to 8
Knob Parameter Adjustment Setting values
1 Scroll Scroll 1 to 5
Knob Parameter Adjustment Setting values
3 Menu/
Action
Select the menu
or action
1 to 43
Knob Parameter Adjustment Setting values
1 Button
Assign No
Select function
to be assigned to
button
1 to 8
