Using Keys 5 to 8
Appendix (Volume 1)
Using Keys 5 to 8
Keys 5 to 8 cannot be used when the signal format is
1080P.
Assigning Buttons for Selection of Keys 5 to 8 in the Setup Menu
In the factory defaults for this system, keys 5 to 8 are not
assigned to buttons on the control panel.
To select keys 5 to 8, assign buttons in the Setup menu
according to the following table.
Notes
Control block Button Menu number Reference in User Guide
“Control Panel Setup (Panel)” and “Cross-Point Settings (Xpt
Assign Menu)” in Chapter 19 (Volume 2)
Transition control
block
Next transition
selection buttons
7321.9 “Setting Transition Control Block Button Assignments”
Engineering Setup >Panel >Config >Link/Program Button
>Transition Module1 menu
Cross-point control
block
SHIFT button 7322.1 “Creating Cross-Point Assign Tables” “Setting the action of the
[SHIFT] button in the cross-point control block”
Engineering Setup >Panel >Xpt Assign >Table Button Assign
menu
Key control block Delegation button 7321.35 “Assigning Functions to Key Control Block Buttons”
Engineering Setup >Panel >Config >Link/Program Button
>CCP-9000 Key Deleg menu
Transition control
block
Independent key
transition execution
section
7321.34 “Setting Transition Control Block Button Assignments”
Engineering Setup >Panel >Config >Link/Program Button
>Transition Module3 menu
Downstream key
control block
Key delegation
buttons
7321.1 “Assigning the Key Delegation in the Downstream Key Control
Block”
Engineering Setup >Panel >Config >DSK Fader Assign menu
Device control block
(joystick)
Operating buttons 7321.31 “Selecting the Module to be the Reference for Device Control
Block”
Engineering Setup >Panel >Config >JS/TB User Setting menu
Device control block
(trackball)
