Sony MVS-7000X - Applying a DME Effect to a Key

113
Key Adjustments (Key Control Block)
Chapter 4 Keys
When pattern is selected
a) The pattern is the same as a standard wipe. (See “Wipe Pattern List” (page
308).)
Using the subsidiary mask
In the key control block, press the [SUB MASK] button,
turning it on. The parameter settings depend on the mask
source selected as [Wipe] or [Utility 1 Bus] in the <Mask
Source> group of the Sub Mask menu for the key.
When wipe is selected
When utility 1 bus is selected
Applying a DME Effect to a Key
• When the SDI interface is used to connect the DME,
DME effects (including DME wipes) can be used in only
one place for one M/E bank.
• When the dedicated interface is used to connect the
DME, the number of keys to which DME effects
(including DME wipes) can be applied simultaneously
for one M/E bank varies as follows depending on the
execution mode of the DME wipe pattern selected for the
background.
- MVS-8000X
- MVS-7000X
a) 0 when the system signal format is 1080P.
b) 1 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
c) 0 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
• When combining DMEs connected via the dedicated
interface and the SDI interface, you can increase the
number of keys to which DME effects are applied
simultaneously. (Requires a setting in setup.)
For details, see “Setting DME and Switcher Interfaces”
in Chapter 20 (Volume 2).
Assigning a DME to a key
1 In the key control block, press the delegation buttons
[M/E1] and [KEY1].
Knob Parameter Adjustment Setting values
1 Size Pattern size 0 to 100
2 Soft Edge softness 0 to 100
3 Pattern Pattern number 1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0 to 100
2 Soft Edge softness 0 to 100
Knob Parameter Adjustment Setting values
1 Clip Reference level for
creating mask
signal
+109 to –7
2 Gain Gain –100 (shown as
–00) to +100
Notes
Applicable
block
Key to
which
DME
effects
are
applied
DME wipe
pattern for
background
Number of keys
to which DME
effects can be
applied
simultaneously
Other than
M/E-4
Keys 1
to 4
No DME
wipe used
2
One-channel
mode
1
Two - o r
three-
channel
mode
0
Keys 5
to 8
-
2
a)
M/E-4 Keys 1
to 4
No DME
wipe used
2
b)
One-channel
mode
1
c)
Two - o r
three-
channel
mode
0
Keys 5
to 8
-0
Key to
which
DME
effects are
applied
DME wipe pattern
for background
Number of keys to
which DME effects
can be applied
simultaneously
Keys 1 to 4 No DME wipe used 2
One-channel mode 1
Two- or three-
channel mode
0
Keys 5 to 8 -
2
a)
