Sony MVS-7000X - Wipe Modify Clear

135
Basic Procedure for Wipe Settings
Chapter 5 Wipes
• The parameter Magnitude determines the size and
direction of the spiral.
A value of –100.00 represents the maximum movement
in the counterclockwise direction, and a value of
+100.00 represents the maximum movement in the
clockwise direction.
• The parameter Wave Speed determines the speed of the
lateral waves.
A value of –100.00 represents the maximum speed to the
left, and a value of +100.00 represents the maximum
speed to the right.
You can set the spiral function independently for the main
and sub patterns.
1 In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2 Press [Spiral], turning it on.
3 Set the following parameters.
Possible combinations of wipe patterns
and modifiers
Yes: Can be used No: Cannot be used
a) Not patterns 1 to 16, 19, and 20
b) Not patterns 300 to 303
c) Not patterns 100 to 103, 150, 151, 516, 518, 604, and 606
d) Not patterns 1 to 8, 17, and 18
e) Not patterns 220 to 223
f) Not patterns 19 and 20
g) But patterns 21, 23 and 24 are possible
h) But patterns 21 and 23 are possible
Wipe Modify Clear
Press [Default Recall] at the lower left of the menu display,
turning it on, then press VF5 ‘Wipe’ to return the wipe
settings to their initial status.
For details of the menu operation to return the wipe state
to that set in initial status, see “Returning to Default State
in Function Groupings” (page 60).
Knob Parameter Adjustment Setting values
1 Magnitude Size and
direction of the
spiral
–100.00 to
+100.00
2Wave
Speed
Speed of the
lateral waves
–100.00 to
+100.00
Modifiers Type of wipe
Standard Enhanced Rotary Mosaic Random/
diamond
dust
Direction Yes Yes Yes Yes Yes
Split Yes Ye s N o Ye s N o
Edge Yes Yes Yes Yes Yes
Positioner Ye s
a)
Ye s
b)
Ye s
c)
No No
Rotation Ye s Ye s Ye s
c)
No No
Aspect
ratio
Ye s
d)
Ye s N o N o N o
Pattern
replication
Yes Yes Yes Yes
e)
No
Pairing Ye s
f)
Ye s N o N o N o
Modulation
(H/V)
Ye s Ye s Ye s N o N o
Modulation
(Fringe)
No
g)
Ye s N o N o N o
Spring No
g)
Ye s N o N o N o
Spiral No
h)
Ye s N o N o N o
