504
Auxiliary Bus Control Block Settings (Aux Assign Menu)
Chapter 19 Control Panel Setup (Panel)
2
Press [Set] to confirm the selection.
To set the AUX delegation button shift operation
To set the operation mode of the rightmost button in the
row of AUX delegation buttons, select one of the
following in the <Shift Mode> group of the Panel >Aux
Assign menu.
Hold: Acts as a shift button, and the shifted version of the
AUX delegation buttons is enabled while the button is
held down.
Lock: Acts as a shift button, and pressing the button
toggles between the shifted version and the unshifted
version of the AUX delegation buttons.
Off: Acts as an AUX delegation button. In a 16-button
system it acts as button number 16, in a 24-button
system as button number 24, and in a 32-button system
as button number 32.
Using the Auxiliary Bus Control
Block for Router Control
To make router control settings, display the Setup >Panel
>Aux Assign >RTR Mode Setting menu.
This menu is used to make settings related to “Router
Control Menu Operations” in Chapter 8 (Volume 1).
To display the RTR Mode Setting menu
1
In the Engineering Setup menu, select VF2 ‘Panel’ and
HF3 ‘Aux Assign.’
The Aux Assign menu appears.
2
Press [RTR Mode Setting].
The RTR Mode Setting menu appears. The left of the
status area shows the destination number assignment
status and source table, and the right side lists the
destinations that can be assigned.
Assigning a destination to a destination
selection button
In the Panel >Aux Assign >RTR Mode Setting menu, use
the following procedure.
1
Using any of the following methods, select a
destination selection button and the destination to be
assigned to the button.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knobs.
For a button whose operation you want to disable,
press [Inhibit].
When a destination selection button having a number
in the range 65 to 128 is selected, source table
selection automatically becomes invalid, and therefore
the Inhibit function also becomes invalid.
2
Press [Dest Set] to confirm the selection.
3
If in step 1 you selected a value in the range 1 to 64, turn
the knob to select the source table.
4
Press [Source Table Set] to confirm the selection.
5
Repeat steps 1 to 4 as required.
To set the shift operation of the destination
selection buttons
To set the operation mode of the rightmost button in the
destination selection button row, select one of the
following in the <Dest Shift Mode> group of the Panel
>Aux Assign >RTR Mode Setting menu.
Hold: Acts as a shift button, and the shifted destination
selection buttons are enabled while the button is held
down.
Lock: Acts as a shift button, and pressing the button
toggles between the shifted and unshifted states of the
destination selection buttons.
Off: Acts as a destination selection button, that is, button
number 16 on a 16-button system, button number 24
on a 24-button system, and button number 32 on a 32-
button system.
Setting the source table
1
In the Panel >Aux Assign >RTR Mode Setting menu,
press [Source Table Assign].
The Source Table Assign menu appears.
2
In the <Source Table Select> group, select the source
table you want to manipulate.
Knob Parameter Adjustment Setting values
1 Dest No Destination
selection button
selection
1 to 128
2 No Destination
selection in S-Bus
space
1 to 1024
Notes
Knob Parameter Adjustment Setting values
3Source
Table
Source table
selection
1 to 5
To Next Page
