65
Signal Selection
Chapter 3 Signal Selection and Transitions
a) An assignment is required for keys 5 to 8.
b) To turn on the [DME1] to [DME4] buttons requires one of the [KEY1] to
[KEY8] and [DSK1] to [DSK8] buttons to be on.
c) An assignment to the delegation buttons is required in setup, to assign the
bus for operations.
Signal Assignment and Selection
Assigning signals to buttons
Each cross-point button has a button number, to which you
assign a signal.
In addition to the signals input to the following connectors,
you can also select signals generated within the switcher.
• The PRIMARY INPUTS connectors on the rear panel of
the switcher (1 to 144 in MVS-8000X, 1 to 80 in MVS-
7000X)
• The PREMIUM INPUTS 1 to 20 connectors (only in
MVS-8000X)
• The FC INPUTS 1 to 16 connectors (only in MVS-
8000X)
Each button has assigned to it a video signal and a key
signal, forming a pair. You can set these video and key
combinations in a Setup menu.
PGM/PST Program bus Program row −
Preset bus Preset row −
DSK 1 bus DSK row Turn on the button to which the
corresponding key is assigned.
DSK 2 bus
DSK 3 bus
DSK 4 bus
DSK 5 bus
a)
DSK 6 bus
a)
DSK 7 bus
a)
DSK 8 bus
a)
M/E-1, PGM/
PST
Utility 1 bus Key row Turn on the [UTIL1] button
Utility 2 bus Turn on the [UTIL2] button
DME 1 video bus Turn on the [DME1] button
b)
DME 2 video bus Turn on the [DME2] button
b)
DME 3 video bus Turn on the [DME3] button
b)
DME 4 video bus Turn on the [DME4] button
b)
Auxiliary bus
control block
c)
AUX1 to AUX48 buses The key row of the bank selected
with the bank selection buttons
in the auxiliary bus control block
Turn on the appropriate buttons in
accordance with the signal assignment
made in the Setup menu.
Frame memory source 1 and
frame memory source 2 buses
DME 1 to DME 4 video buses
DME 1 to DME 4 key buses
Edit preview bus
M/E-1 UTILITY 1 and
M/E-1 UTILITY 2 buses
P/P UTILITY 1 and P/P UTILITY
2 buses
M/E-1 Key 1 fill to M/E-1 Key 8 fill
buses
M/E-1 Key 1 source to M/E-1 Key
8 source buses
DSK 1 fill to DSK 8 fill buses
DSK 1 source to DSK 8 source
buses
M/E-1 external DME bus
P/P external DME bus
DME UTILITY 1 and DME
UTILITY 2 buses
Bank Bus name Cross-point button row Delegation operation
