Interfacing With External Devices (Device Interface Menu)
Chapter 19 Control Panel Setup (Panel)
recall button. To set a name for display in a memory recall
button to which “Shotbox Recall” or “Macro Recall” has
been assigned, use the Shotbox menu or Macro menu.
1
In the Prefs/Utility >Utility Module Assign menu,
select the button using any of the following methods.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knobs.
2
Press [Name].
A keyboard window appears.
3
Enter a name of not more than eight characters, and
press [Enter].
The name you have set is reflected in the status area
and on the memory recall button in the utility/shotbox
control block.
Interfacing With External
Devices (Device Interface
Menu)
To carry out setup relating to connections with external
devices, display the Panel >Device Interface menu.
To display the Device Interface menu
In the Engineering Setup menu, select VF2 ‘Panel’ and
HF5 ‘Device Interface.’
The following functions are available here.
• GPI Input: Set the GPI input ports and trigger type, and
make the action settings.
• GPI Output: Set the GPI output ports and trigger type,
and make the action settings.
• P-Bus Control: Set the control mode for P-Bus devices.
• DCU Serial Port Assign: Assign the devices (disk
recorder/VTR/Extended VTR) connected to a DCU and
accessible from the control panel to the [DEV1] to
[DEV12] buttons which become operative when you
press the [DEV] button on the device control block. For
a disk recorder or Extended VTR, you can also make
settings relating to sharing of file lists. Further, you can
make settings for devices (disk recorder/VTR/Extended
VTR) operable from an editing keyboard.
• Editor Port Assign: When the BZS-8050 license is
valid, make settings for the SCU editor panel port.
• Aux Bus Override Mode: Set the operating mode when
“Aux ? O’ride Src ??” is selected as the GPI input action.
Making Control Panel GPI Input
Settings
1
In the Panel >Device Interface menu, press [GPI
Input].
The GPI Input menu appears.
2
Using any of the following methods, select the
settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
3
In the <Trigger Type> group, select the trigger type.
(Rising Edge): Apply the trigger on a rising
edge of an input pulse.
Knob Parameter Adjustment Setting values
1 Bank Bank selection 1 to 4
2 Button No Control block
button selection
1 to 24
Knob Parameter Adjustment Setting values
1 Port Port selection 1 to 8
