512
Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
a) For the safe title on/off commands (from ME1 PGM1 ST-ME1 PGM4 ST
to AUX1 ST-AUX48 ST), the name of the assigned output signal is
shown.
b) Pressing this button to turn it on enables key snapshot operations for all
control blocks.
Assigning a menu shortcut to a memory
recall button
1
Referring to the procedure up to step 3 on “Assigning
a Function to a Memory Recall Button in the Utility/
Shotbox Control Block (MKS-8033 Utility/Shotbox
Module, Option)” (page 509), select [Menu Shortcut].
The memory recall buttons in the utility/shotbox
control block flash orange.
2
Using any of the following methods, display the menu
to which you want to make a shortcut.
• In the menu control block, press the relevant top
menu selection button, then select VF and HF.
• Press the menu page number button in the upper left
corner of the menu screen, then enter a menu number
from the numeric keypad window.
• Press a particular control panel button twice in rapid
succession.
3
In the utility/shotbox control block, select the bank,
and press the button to which you want to assign the
shortcut.
The menu screen goes back to the Prefs/Utility
>Utility Module Assign menu, and the selection is
reflected in the status area.
The buttons in the utility/shotbox control block flash.
4
Repeat steps 2 and 3 as required, to assign all desired
menu shortcuts to the buttons in the utility/shotbox
control block.
To abandon the process of menu shortcut
assignment
In the Prefs/Utility >Utility Module Assign menu, press
[Menu Shortcut].
This exits the menu shortcut assignment mode.
Setting names to be displayed in memory
recall buttons
The name you set using the following procedure is
displayed only when “Menu Shortcut” or “Utility
Command” has been assigned to the selected memory
Pre Macro Set macro attachment in pre macro mode Can be set only while
pressed (lit)
When the function is
assigned
Post Macro Set macro attachment in post macro mode Can be set only while
pressed (lit)
When the function is
assigned
Macro Take Macro execution During execution When the function is
assigned
Macro Auto Ins Macro auto insert mode on/off On Off
Macro AT with Rate When registering an auto transition macro
event, on/off setting of mode to save transition
rate
On Off
Macro AT with A/B Bus When registering an auto transition macro
event for the transition control block, on/off
setting of mode to save A/B Bus cross-point
settings
On Off
Macro TL with Region When registering a timeline macro event, on/
off setting of mode to save applicable region
On Off
DME Override DME override on/off On Off
DME Graphic DME graphics on/off (Applies to graphics for
channel selected in device control block)
On Off
Plug-In Editor Enbl Enable/disable operation from an editing
keyboard
Enabled Disabled
Inhibit Set Inhibit cross-point button Can be set only while
pressed (lit)
When the function is
assigned
Inhibit All Clear Clear all cross-point button inhibit settings Can be set only while
pressed (lit)
When the function is
assigned
K-SS Store
b)
Enable/disable key snapshot saving Enabled Disabled
Command name
a)
Function Button status
Lit green Lit orange
Notes
