511
Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
ME4 PGM1 ST
|
ME4 PGM4 ST
M/E-4 PGM1 output safe title On/Off
|
M/E-4 PGM4 output safe title On/Off
On Off
ME4 PVW ST M/E-4 preview output safe title On/Off On Off
ME4 Clean ST M/E-4 clean output safe title On/Off On Off
ME4 K-PVW ST ME-4 key preview output safe title On/Off On Off
PP PGM1 ST
|
PP PGM4 ST
PP PGM1 output safe title on/off
|
PP PGM4 output safe title on/off
On Off
PP PVW ST P/P preview output safe title on/off On Off
PP Clean ST P/P clean output safe title on/off On Off
PP K-PVW ST P/P key preview output safe title on/off On Off
DME MON1 ST DME Monitor 1 output safe title on/off On Off
DME MON2 ST DME Monitor 2 output safe title on/off On Off
Edit PVW ST Edit preview output safe title on/off On Off
Preset ST Preset output safe title on/off On Off
AUX1 ST
|
AUX48 ST
AUX1 output safe title on/off
|
AUX48 output safe title on/off
On Off
FM Src1 Frame Freeze Frame freeze of frame memory source 1 During frame freeze Either of the other two
states
FM Src1 Filed Freeze Field freeze of frame memory source 1 During field freeze Either of the other two
states
FM Src1 Freeze Off Release freeze of frame memory source 1 While freeze being
released
Either of the other two
states
FM Src2 Frame Freeze Frame freeze of frame memory source 2 During frame freeze Either of the other two
states
FM Src2 Field Freeze Field freeze of frame memory source 2 During field freeze Either of the other two
states
FM Src2 Freeze Off Release freeze of frame memory source 2 While freeze being
released
Either of the other two
states
SWR GPI Enbl Enable/disable switcher GPI Enabled Disabled
DME1 GPI Enbl Enable/disable DME1 GPI Enabled Disabled
DME2 GPI Enbl Enable/disable DME2 GPI Enabled Disabled
DME3 GPI Enbl Enable/disable DME3 GPI Enabled Disabled
DME4 GPI Enbl Enable/disable DME4 GPI Enabled Disabled
Panel GPI Enbl Enable/disable panel GPI Enabled Disabled
SWR GPI1 Test Fire
|
SWR GPI8 Test Fire
Output test trigger from switcher GPI1
|
Output test trigger from switcher GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Panel GPI1 Test Fire
|
Panel GPI8 Test Fire
Output test trigger from panel GPI1
|
Output test trigger from panel GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
DCU GPI1 Test Fire
|
DCU GPI50 Test Fire
Output test trigger from port assigned to DCU
GPI1
|
Output test trigger from port assigned to DCU
GPI50
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Macro Attachment Enbl Enable/disable macro attachment Enabled Disabled
Macro Only Set Macro only mode on/off On Off
Command name
a)
Function Button status
Lit green Lit orange
