510
Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
Turn the knob.
a) When the Command parameter is set to Sw’er GPI Test Fire, Panel
GPI Test Fire, DCU GPI, or Test Fire
When Macro Recall is selected: Turn the knob to
select the macro register you want to assign.
When Shotbox Recall is selected: Turn the knob to
select the shotbox register you want to assign.
5
Press [Action Set].
This assigns the selected action, which is reflected in
the status area.
In the utility/shotbox control block, the assigned
button lights orange.
If a shotbox register was assigned, the register name
appears.
To cancel an assignment
After selecting the relevant button, press [Clear].
To display register names in the Utility Command
column
If in step 3 you select [Macro Recall] or [Shotbox Recall],
press the [Reg Name Display] button to select whether or
not register names appear in the Utility Command column.
List of utility commands and memory recall button status
The following table shows the utility commands that can
be assigned to memory recall buttons.
Knob Parameter Adjustment Setting values
3 Command Utility command
selection
1 and upwards
4
a)
GPI No GPI port number 1 and upwards
Knob Parameter Adjustment Setting values
3 Macro Macro register
selection
1 to 250
Knob Parameter Adjustment Setting values
3 Shotbox Shotbox register
selection
1 to 99
Command name
a)
Function Button status
Lit green Lit orange
SWR Remote1 Enbl
|
SWR Remote4 Enbl
Switcher Remote 1 enabled/disabled
|
Switcher Remote 4 enabled/disabled
Enabled Disabled
DME1 Editor Port Enbl DME1 editor port enabled/disabled Enabled Disabled
DME2 Editor Port Enbl DME2 editor port enabled/disabled Enabled Disabled
DME3 Editor Port Enbl DME3 editor port enabled/disabled Enabled Disabled
DME4 Editor Port Enbl DME4 editor port enabled/disabled Enabled Disabled
ME1 PGM1 ST
|
ME1 PGM4 ST
M/E-1 PGM1 output safe title on/off
|
M/E-1 PGM4 output safe title on/off
On Off
ME1 PVW ST M/E-1 preview output safe title on/off On Off
ME1 Clean ST M/E-1 clean output safe title on/off On Off
ME1 K-PVW ST M/E-1 key preview output safe title on/off On Off
ME2 PGM1 ST
|
ME2 PGM4 ST
M/E-2 PGM1 output safe title on/off
|
M/E-2 PGM4 output safe title on/off
On Off
ME2 PVW ST M/E-2 preview output safe title on/off On Off
ME2 Clean ST M/E-2 clean output safe title on/off On Off
ME2 K-PVW ST M/E-2 key preview output safe title on/off On Off
ME3 PGM1 ST
|
ME3 PGM4 ST
M/E-3 PGM1 output safe title on/off
|
M/E-3 PGM4 output safe title on/off
On Off
ME3 PVW ST M/E-3 preview output safe title on/off On Off
ME3 Clean ST M/E-3 clean output safe title on/off On Off
ME3 K-PVW ST ME-3 key preview output safe title on/off On Off
