344
Using the M/E-4 Bank
Appendix (Volume 1)
Using the M/E-4 Bank
Assigning a Button for M/E-4 Selection in the Setup Menu
• In the factory defaults for this system, M/E-4 is not
assigned to buttons on the control panel.
• To select M/E-4, assign buttons in the Setup menu
according to the following table.
Control block Button Menu number Reference in User Guide
“Control Panel Setup (Panel)” and “Cross-Point Settings (Xpt
Assign Menu)” in Chapter 19 (Volume 2)
Cross-point control
block
Reentry buttons 7322.1
7322.5
“Creating Cross-Point Assign Tables”
Engineering Setup >Panel >Xpt Assign >Table Button Assign
menu
Engineering Setup >Panel >Xpt Assign >Main,V/K Pair Assign
menu
Entire switcher bank - 7321 “Interchanging the Bank Order or Disabling Operation”
Engineering Setup >Panel >Config menu
Key control block Delegation buttons 7321.29 “Assigning Functions to Key Control Block Buttons”
Engineering Setup >Panel >Config >Link/Program Button >Key
Control Module >Button Assign menu
Device control block Region selection
buttons
7321.17 “Assigning Functions to the Device Control Block”
Engineering Setup >Panel >Config >Link/Program Button
>Joystick/Trackball Module menu
Numeric keypad
control block
Region selection
buttons
7321.7 “Assigning a Region to the Region Selection Buttons in the
Numeric Keypad Control Block”
Engineering Setup >Panel >Config >10 Key Region Assign
menu
Menu control block Top menu selection
buttons
7321.19 “Assigning Functions to the Menu Control Block Top Menu and
User Preference Buttons”
Engineering Setup >Panel >Config >Link/Program Button
>Menu Panel menu
To Next Page
