509
Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
a) For the safe title on/off commands (from ME1 PGM1 ST-ME1 PGM4 ST
to AUX1 ST-AUX48 ST), the name of the assigned output signal is
shown.
b) Pressing this button to turn it on enables key snapshot operations for all
control blocks.
Assigning a menu shortcut to a user
preference button
1
Referring to the procedure up to step 2 of “Assigning
Functions to User Preference Buttons” (page 506),
select [Menu Shortcut].
The user preference buttons [PREFS 1] to [PREFS 16]
flash amber.
2
Using any of the following methods, display the menu
to which you want to make a shortcut.
• In the menu control block, press the relevant top
menu selection button, then select VF and HF.
• Press the menu page number button in the upper left
corner of the menu screen, then enter a menu number
from the numeric keypad window.
• Press a particular control panel button twice in rapid
succession.
3
Press the user preference button to which you want to
assign the shortcut.
The menu screen goes back to the Prefs/Utility menu,
and the selection is reflected in the status area. The
user preference buttons [PREFS 1] to [PREFS 16]
flash amber.
4
Repeat steps 2 and 3 as required, to assign all desired
menu shortcuts to the user preference buttons.
To abandon the process of menu shortcut
assignment
In the Prefs/Utility menu, press [Menu Shortcut] once
more.
This exits the menu shortcut assignment mode.
Assigning a Function to a Memory
Recall Button in the Utility/Shotbox
Control Block (MKS-8033 Utility/
Shotbox Module, Option)
1
In the Prefs/Utility menu, press [Utility Module
Assign].
The Prefs/Utility >Utility Module Assign menu
appears. The status area shows the settings in the
utility/shotbox control block.
2
Using any of the following methods, select the button
to be assigned.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knobs.
3
In the
<Action> gr
oup, select t
he funct
ion you want
to
assign.
Menu Shortcut: Assign a frequently used menu to be
recalled (menu shortcut).
Utility Command: Assign a function on/off or similar
operation (utility command).
Macro Recall: Assign a macro register recall.
Shotbox Recall: Assign a shotbox register recall.
4
Depending on the selection in step 3, make the
following settings.
When Menu Shortcut is selected: For the subsequent
operations, see the next item “Assigning a menu
shortcut to a memory recall button” (page 512).
When Utility Command is selected: A list of
commands appears on the right of the status area;
using any of the following methods, select the
command you want to assign.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video
cursor.
Inhibit Set Inhibit cross-point button Can be set only while
pressed (lit)
When the function is
assigned
Inhibit All Clear Clear all cross-point button inhibit settings Can be set only while
pressed (lit)
When the function is
assigned
K-SS Store Enable/disable key snapshot saving
b)
Enabled Disabled
Command name
a)
Function Button status
Lit amber Off
Knob Parameter Adjustment Setting values
1 Bank Bank selection 1 to 4
2 Button No Control block
button selection
1 to 24
To Next Page
