Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
FM Src1 Filed Freeze Field freeze of frame memory source 1 During field freeze Either of the other two
states
FM Src1 Freeze Off Release freeze of frame memory source 1 While freeze being
released
Either of the other two
states
FM Src2 Frame Freeze Frame freeze of frame memory source 2 During frame freeze Either of the other two
states
FM Src2 Field Freeze Field freeze of frame memory source 2 During field freeze Either of the other two
states
FM Src2 Freeze Off Release freeze of frame memory source 2 While freeze being
released
Either of the other two
states
SWR GPI Enbl Enable/disable switcher GPI Enabled Disabled
DME1 GPI Enbl Enable/disable DME1 GPI Enabled Disabled
DME2 GPI Enbl Enable/disable DME2 GPI Enabled Disabled
DME3 GPI Enbl Enable/disable DME3 GPI Enabled Disabled
DME4 GPI Enbl Enable/disable DME4 GPI Enabled Disabled
Panel GPI Enbl Enable/disable panel GPI Enabled Disabled
SWR GPI1 Test Fire
|
SWR GPI8 Test Fire
Output test trigger from switcher GPI1
|
Output test trigger from switcher GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Panel GPI1 Test Fire
|
Panel GPI8 Test Fire
Output test trigger from panel GPI1
|
Output test trigger from panel GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
DCU GPI1 Test Fire
|
DCU GPI50 Test Fire
Output test trigger from port assigned to DCU
GPI1
|
Output test trigger from port assigned to DCU
GPI50
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Macro Attachment Enbl Enable/disable macro attachment Enabled Disabled
Macro Only Set Macro only mode on/off On Off
Pre Macro Set macro attachment in pre macro mode Can be set only while
pressed (lit)
When the function is
assigned
Post Macro Set macro attachment in post macro mode Can be set only while
pressed (lit)
When the function is
assigned
Macro Take Macro execution During execution When the function is
assigned
Macro Auto Ins Macro auto insert mode on/off On Off
Macro AT with Rate When registering an auto transition macro
event, on/off setting of mode to save transition
rate
On Off
Macro AT with A/B Bus When registering an auto transition macro
event for the transition control block, on/off
setting of mode to save A/B Bus cross-point
settings
On Off
Macro TL with Region When registering a timeline macro event, on/
off setting of mode to save applicable region
On Off
DME Override DME override on/off On Off
DME Graphic DME graphics on/off (Applies to graphics for
channel selected in device control block)
On Off
System Manager Enbl Enable/disable operation from System
Manager
Enabled Disabled
Plug-In Editor Enbl Enable/disable operation from an editing
keyboard
Enabled Disabled
Command name
a)
Function Button status
Lit amber Off
