Setting Button Assignments (Prefs/Utility Menu)
Chapter 19 Control Panel Setup (Panel)
List of utility commands and user preference button status
The following table shows the utility commands that can
be assigned to user preference buttons.
Command name
a)
Function Button status
Lit amber Off
SWR Remote1 Enbl
|
SWR Remote4 Enbl
Switcher Remote 1 enabled/disabled
|
Switcher Remote 4 enabled/disabled
Enabled Disabled
DME1 Editor Port Enbl DME1 editor port enabled/disabled Enabled Disabled
DME2 Editor Port Enbl DME2 editor port enabled/disabled Enabled Disabled
DME3 Editor Port Enbl DME3 editor port enabled/disabled Enabled Disabled
DME4 Editor Port Enbl DME4 editor port enabled/disabled Enabled Disabled
ME1 PGM1 ST
|
ME1 PGM4 ST
M/E-1 PGM1 output safe title on/off
|
M/E-1 PGM4 output safe title on/off
On Off
ME1 PVW ST M/E-1 preview output safe title on/off On Off
ME1 Clean ST M/E-1 clean output safe title on/off On Off
ME1 K-PVW ST M/E-1 key preview output safe title on/off On Off
ME2 PGM1 ST
|
ME2 PGM4 ST
M/E-2 PGM1 output safe title on/off
|
M/E-2 PGM4 output safe title on/off
On Off
ME2 PVW ST M/E-2 preview output safe title on/off On Off
ME2 Clean ST M/E-2 clean output safe title on/off On Off
ME2 K-PVW ST M/E-2 key preview output safe title on/off On Off
ME3 PGM1 ST
|
ME3 PGM4 ST
M/E-3 PGM1 output safe title on/off
|
M/E-3 PGM4 output safe title on/off
On Off
ME3 PVW ST M/E-3 preview output safe title on/off On Off
ME3 Clean ST M/E-3 clean output safe title on/off On Off
ME3 K-PVW ST ME-3 key preview output safe title on/off On Off
ME4 PGM1 ST
|
ME4 PGM4 ST
M/E-4 PGM1 output safe title On/Off
|
M/E-4 PGM4 output safe title On/Off
On Off
ME4 PVW ST M/E-4 preview output safe title On/Off On Off
ME4 Clean ST M/E-4 clean output safe title On/Off On Off
ME4 K-PVW ST ME-4 key preview output safe title On/Off On Off
PP PGM1 ST
|
PP PGM4 ST
P/P PGM1 output safe title on/off
|
P/P PGM4 output safe title on/off
On Off
PP PVW ST P/P preview output safe title on/off On Off
PP Clean ST P/P clean output safe title on/off On Off
PP K-PVW ST P/P key preview output safe title on/off On Off
DME MON1 ST DME Monitor 1 output safe title on/off On Off
DME MON2 ST DME Monitor 2 output safe title on/off On Off
Edit PVW ST Edit preview output safe title on/off On Off
Preset ST Preset output safe title on/off On Off
AUX1 ST
|
AUX48 ST
AUX1 output safe title on/off
|
AUX48 output safe title on/off
On Off
FM Src1 Frame Freeze Frame freeze of frame memory source 1 During frame freeze Either of the other two
states
