Key Setting Operations with the Cross-Point Control Block
Chapter 4 Keys
- MVS-7000X
a) 0 when the system signal format is 1080P.
b) 1 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
c) 0 when the system signal format is 1080P and the DME input/output
signal format is set to dual link mode.
• When combining DMEs connected via the dedicated
interface and the SDI interface, you can increase the
number of keys to which DME effects are applied
simultaneously. (Requires a setting in setup.)
For details, see “Setting DME and Switcher Interfaces”
in Chapter 20 (Volume 2).
Ending a DME assignment
As an example, to end the assignment of a DME to key 1,
in the cross-point control block, hold down the key row
delegation button [KEY1] and press the DME button
([DME1] to [DME4]) that is lit green.
The button goes off, and this ends the assignment.
Selecting the video signal for a DME
assigned to a key
When using the dedicated interface, proceed as follows.
1
In the cross-point control block, press the key row
delegation button [KEY1].
The assigned DME button lights amber.
2
Press the DME button (one of [DME1] to [DME4]) lit
amber, which then lights green.
3
To select the video signal for the side of the DME
image that is currently visible, make the signal
selection in the key row.
4
To select the video signal for the side of the DME
image that is currently not visible (the back side), hold
down the DME button (one of [DME1] to [DME4])
and make the signal selection in the key row.
When two or more DME channels are assigned, select the
video signal for each DME in the same way.
When using the SDI interface
For keyer channels 3 and 4, select the video signals on the
AUX bus assigned in a Setup menu (Engineering Setup
>Switcher >Device Interface >DME Setting >DME SDI
Interface).
In setup (Engineering Setup >Switcher >Device Interface
menu), if “Dual DME units” is selected, the second
channel video signal is also selected on the AUX bus.
For details, see “Interfacing With External Devices
(Device Interface Menu)” in Chapter 19 (Volume 2).
Key to
which
DME
effects are
applied
DME wipe pattern
for background
Number of keys to
which DME effects
can be applied
simultaneously
Keys 1 to 4 No DME wipe used 2
One-channel mode 1
Two- or three-
channel mode
0
Keys 5 to 8 -
2
a)
