121
Resizer
Chapter 4 Keys
Applying a mosaic
1
In the M/E-1 >Key1 >Processed Key >Enhanced
Effect menu, press [Mosaic], turning it on.
2
Set the parameters.
This operation is the same as the DME mosaic setting.
For more details, see “Mosaic Settings” (page 258).
3
In the < Mosaic/Defocus Mode > group, select the
signal to which to apply the mosaic effect.
Video/Key: Video signal and key signal
Video: Video signal only
If mosaic is enabled, and in the <Mosaic/Defocus
Mode> group you select Video/Key, then the crop and
mask are disabled.
4
Set the parameters.
To make the mosaic like a relief pattern
1
With [Mosaic] on, press [Relief], turning it on.
2
In addition to the mosaic parameters, set the following
parameters.
Defocusing
1
In the M/E-1 >Key1 >Processed Key >Enhanced
Effect menu, press [Defocus], turning it on.
2
Set the parameters.
This operation is the same as the defocusing setting
when using the DME with the DME dedicated
interface (see page 254).
However, <Mosaic/Defocus Mode> appears in place
of <Defocus Mode>.
If defocus is enabled, and in the <Mosaic/Defocus Mode>
group you select Video/Key, then the crop and mask are
disabled.
Applying a mask to mosaic or defocus
1
In the M/E-1 >Key1 >Processed Key >Enhanced
Effect menu, press [Dual Rszr Effect], turning it on.
2
Press [Mask], turning it on.
This enables the mask function.
To make the mask settings, continue with steps 3 and
following.
3
Press [Mask Menu].
The Mask menu appears.
4
In the <Mask Source> group, select either of [Box]
and [Circle].
Box: Use a box pattern as the mask signal.
Circle: Use a circle pattern as the mask signal.
5
Set the parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
The parameters are the same as for drop shadow.
For more details, see “Applying a drop shadow”
(page 120), except that knobs 3 and 5 are as follows.
The rotation and inversion operations are the same as
for a DME mask setting.
For more details, see “Mask Settings” (page 261).
Knob Parameter Adjustment Setting values
1 H Horizontal gain
adjustment
0.00 to 100.00
2 V Vertical gain
adjustment
0.00 to 100.00
3 All Both horizontal
and vertical
adjustment
H value is
displayed
Notes
Knob Parameter Adjustment Setting values
1H Horizontal
defocusing
0.00 to 100.00
2V Vertical
defocusing
0.00 to 100.00
3 All Horizontal and
vertical
defocusing
H value shown
Knob Parameter Adjustment Setting values
3 Gain Relief depth of
mosaic cells
0.00 to 100.00
4 Angle Light source
direction
–8.00 to +8.00
Notes
Knob Parameter Adjustment Setting values
3 Size Size 0.00 to 100.00
5 Aspect Aspect ratio –100.00 to
+100.00
