141
Overview
Chapter 6 DME Wipes
Pattern
groups
Effects Pattern numbers
One-channel
mode
Two-channel
mode
Three-channel
mode
Slide The new video slides in over the old video. 1001 to 1008 2601 to 2608 —
Squeeze The new video appears squeezed over the old video, and
progressively expands to cover it.
1021 to 1031 2621 to 2628 —
Split The old video splits, and the new video appears in the gap. 1011 to 1013 — —
Door The new video moves like a door closing, and progressively
covers the old video.
10411048 — —
Flip tumble The old video rotates about an axis and is replaced by the
new video. During the transition, the signal from the utility 2
bus of the M/E bank appears as the background.
1101 to 1104,
1109, 1110,
1121, 1122,
1124, 1131 to
1133, 1135
——
Mirror The new video appears over the old video as a mirror effect
slides in all four directions.
1355 to 1358 — —
Sphere The new video appears wrapped around a sphere over the
old video, then returns to the original video while
unwrapping.
1365 — —
Character trail The new video appears with a trail over the old video. Next
this gradually returns to the original from the periphery.
1371, 1372 — —
Wave The new video appears with a wave-like effect over the old
video. Next this returns to the original video as the effect
reduces.
1378, 1379 — —
Ripple The new video appears over the old video like outwardly
moving ripples.
1381 — —
Page turn The old video moves like a page turning, and the new video
appears behind it.
1301 to 1313,
1315 to 1318,
1341 to 1345
2701 to 2713,
2715 to 2718,
2741 to 2745
—
Page roll The new video unrolls like a scroll over the old video. This is
a type of page turn.
1321 to 1333,
1335 to 1338,
1346 to 1350
2721 to 2733,
2735 to 2738,
2746 to 2750
—
Frame in-out Completed in two transitions. In the first transition, the new
video appears, then on the second transition the new video
goes out and the old video returns.
1201 to 1208,
1221 to 1224
2851 to 2854,
2861 to 2864
—
Picture-in-
• In one-channel mode, this completes in two transitions.
- In the first transition, the old video shrinks, and the new
video appears behind it.
- In the second transition, the old video expands again
until it is its original size.
• In two-channel mode, in the first half of the transition, the
old video shrinks, and the new video appears.
- In the second half of the transition, the new video
expands, and the old video disappears.
- You can move the pattern from the current position by a
relative amount.
- During the transition, the signal from the utility 2 bus of
the M/E bank appears as the background.
1251 2651 to 2652 —
2D trans The new video appears over the old video, while
undergoing expansion, two-dimensional rotation and
translation.
1051 to 1058,
1061 to 1064,
1068
——
3D trans • In one-channel mode, the new video appears over the old
video, while undergoing expansion, three-dimensional
rotation and translation.
• In two-channel mode, the old video changes to the new
video while both undergo expansion, three-dimensional
rotation and translation.
1071, 1072,
1074, 1076,
1077, 1088,
1091 to 1094
2631 to 2634,
2642, 2644
—
