192
Video Process
Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
• Key fill bus settings: “Video Processing” (page 106)
• Settings for frame memory source buses 1 and 2:
“Setting video processing” (page 162)
• Settings for Aux 1 to 48 buses: “Making video process
settings for an AUX bus” (page 189)
• Overview of video process: “Video Process” (page 191)
This section describes an example on the background A
bus of the M/E-1 bank.
For the background B bus or utility bus 1 or 2, make the
adjustment with a similar procedure.
Making video process settings for each
bus
1
In the menu control block, press the top menu
selection button [M/E1] and select VF7 ‘Misc’ and
HF2 ‘Video Process.’
2
In the <Bkgd-A> group, press [Video Process],
turning it on.
3
Adjust the following parameters.
To return the parameter settings to the defaults, press
[Unity] in the <Bkgd-A> group.
Knob Parameter Adjustment Setting values
1 Video
Gain
Video signal
gain
–200.00 to
+200.00
2 Y Gain Luminance
signal gain
–200.00 to
+200.00
3 C Gain Chrominance
signal gain
–200.00 to
+200.00
4 Hue Delay Hue delay –180.00 to
+180.00
5Black
Level
Black level –7.31 to
+109.59
