Sony MVS-7000X - Page 213

213
3D Support
Chapter 10 Special Functions
If [1-21 Mode] is selected on MVS-8000X
If [1-2 Mode] is selected on MVS-7000X
If [1-21 Mode] is selected on MVS-7000X
Setting input signals for 3D mode
For each primary input, to select whether separate left and
right signals are used, or the same signal is shared between
left and right, use the following procedure.
PRIMARY INPUTS 99 PRIMARY INPUTS 100
Slot 10
PRIMARY INPUTS 101 PRIMARY INPUTS 102
PRIMARY INPUTS 103 PRIMARY INPUTS 104
::
PRIMARY INPUTS 119 PRIMARY INPUTS 120
Slot 11
PRIMARY INPUTS 121 PRIMARY INPUTS 122
PRIMARY INPUTS 123 PRIMARY INPUTS 124
::
PRIMARY INPUTS 139 PRIMARY INPUTS 140
Slot 12
PRIMARY INPUTS 141 PRIMARY INPUTS 142
PRIMARY INPUTS 143 PRIMARY INPUTS 144
Slot 13
PREMIUM INPUTS 1 PREMIUM INPUTS 2
PREMIUM INPUTS 3 PREMIUM INPUTS 4
::
PREMIUM INPUTS 19 PREMIUM INPUTS 20
Right signals Left signals
Slot 5 Slot 6
PRIMARY INPUTS 1 PRIMARY INPUTS 21
PRIMARY INPUTS 2 PRIMARY INPUTS 22
::
PRIMARY INPUTS 20 PRIMARY INPUTS 40
Slot 7 Slot 8
PRIMARY INPUTS 41 PRIMARY INPUTS 61
PRIMARY INPUTS 42 PRIMARY INPUTS 62
::
PRIMARY INPUTS 60 PRIMARY INPUTS 80
Slot 9 Slot 10
PRIMARY INPUTS 81 PRIMARY INPUTS 101
PRIMARY INPUTS 82 PRIMARY INPUTS 102
::
PRIMARY INPUTS 100 PRIMARY INPUTS 120
Slot 11
PRIMARY INPUTS 121 PRIMARY INPUTS 122
PRIMARY INPUTS 123 PRIMARY INPUTS 124
::
PRIMARY INPUTS 139 PRIMARY INPUTS 140
Slot 12
PRIMARY INPUTS 141 PRIMARY INPUTS 142
PRIMARY INPUTS 143 PRIMARY INPUTS 144
Right signals Left signals
Slot 13
PREMIUM INPUTS 1 PREMIUM INPUTS 2
PREMIUM INPUTS 3 PREMIUM INPUTS 4
::
PREMIUM INPUTS 19 PREMIUM INPUTS 20
Right signals Left signals
Slot 5
PRIMARY INPUTS 1 PRIMARY INPUTS 2
PRIMARY INPUTS 3 PRIMARY INPUTS 4
::
PRIMARY INPUTS 19 PRIMARY INPUTS 20
Slot 6
PRIMARY INPUTS 21 PRIMARY INPUTS 22
PRIMARY INPUTS 23 PRIMARY INPUTS 24
::
PRIMARY INPUTS 39 PRIMARY INPUTS 40
Slot 7
PRIMARY INPUTS 41 PRIMARY INPUTS 42
PRIMARY INPUTS 43 PRIMARY INPUTS 44
::
PRIMARY INPUTS 59 PRIMARY INPUTS 60
Slot 8
PRIMARY INPUTS 61 PRIMARY INPUTS 62
PRIMARY INPUTS 63 PRIMARY INPUTS 64
::
PRIMARY INPUTS 79 PRIMARY INPUTS 80
Right signals Left signals
Slot 5 Slot 6
PRIMARY INPUTS 1 PRIMARY INPUTS 21
PRIMARY INPUTS 2 PRIMARY INPUTS 22
::
PRIMARY INPUTS 20 PRIMARY INPUTS 40
Slot 7 Slot 8
PRIMARY INPUTS 41 PRIMARY INPUTS 61
PRIMARY INPUTS 42 PRIMARY INPUTS 62
::
PRIMARY INPUTS 60 PRIMARY INPUTS 80
Right signals Left signals
