Sony MVS-7000X - Page 259

259
Applying Special Effects (Effects on the Overall Video Signal)
Chapter 11 DME Operations
3 Select the method for applying outlines in the <Sketch
Mode> group.
Sketch: Apply an effect like a sketch.
Edge Color: Enhance the outlines.
Draw: Apply an effect like a line drawing.
Relief: Apply a bas-relief effect.
Sharp: Increase the apparent sharpness.
4 Set the following parameters, according to the method
selected in step 3.
When Sketch is selected
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Edge Color is selected
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Draw is selected
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Relief is selected
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
When Sharp is selected
5 If you selected other than Sharp in step 3, depending
on the necessity, proceed as follows.
To adjust the outline color for Edge Color or Draw
Turn [Edge Matte] on and set the following parameters
to set the outline color.
Knob Parameter Adjustment Setting values
1 Mix Mix amount
for Sketch
video and
input video
0.00 to 100.00
a)
2 Clip Reference
level for
outline
extraction
–100.00 to
+100.00
b)
3 Gain Image gain
for outline
extraction
–100.00 to +100.00
4C GainChroma gain
of input video
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Mix Mix amount
for Edge
Color video
and input
video
0.00 to 100.00
a)
2 Clip Reference
level for
outline
extraction
–100.00 to
+100.00
b)
Knob Parameter Adjustment Setting values
1 Mix Mix amount
for Draw
video and
input video
0.00 to 100.00
a)
2 Clip Reference
level for
outline
extraction
–100.00 to
+100.00
b)
3 Gain Image gain
for outline
extraction
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Mix Mix amount
for Relief
video and
input video
0.00 to 100.00
a)
2 Offset Relief
luminance
level
–100.00 to +100.00
3 Gain Image gain
for outline
extraction
–100.00 to +100.00
4 Angle Direction of
relief image
light source
–8.00 to +8.00
Knob Parameter Adjustment Setting values
1 H Simultane-
ously adjust
the left and
right resolu-
tion
0.00 to 100.00
2 V Simultane-
ously adjust
the top and
bottom
resolution
0.00 to 100.00
3 All Simultane-
ously adjust
the resolu-
tion of all four
sides
0.00 to 100.00
5 Coring Minimum
value of
edge to
emphasize
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
