Sony MVS-7000X - Page 265

265
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
a) Set when Lock is on.
b) Set when Lock is off.
c) Setting for SD 4:3, SD 16:9
d) Setting for HD 4:3, HD 16:9
When Size is selected
a) Set when Lock is on.
b) Set when Lock is off.
c) Setting for SD 4:3, SD 16:9
d) Setting for HD 4:3, HD 16:9
To stop the waves
Press [Lock], turning it on.
With each press, the waves alternately stop and start
moving again.
To select the waveform
Press [Form] and set the following parameters.
When H&V mode is selected
When Size mode is selected
a) 1 (SINE): Sine wave
2 (PARABOLA): Parabola wave
3 (TRIANGLE): Triangular wave
4 (RECTANGLE): Rectangular wave
5 (CIRCLE): Circular wave
6 (CUBIC): Cubic wave
To randomize the modulated waveform
1 Press [Random], turning it on.
2 Set the following parameters.
When H&V mode is selected
When Size mode is selected
To limit the wave range
1 Press [Range], turning it on.
2 Set the following parameters.
3 Offset V
a)
Ver tical
direction in
which to
offset wave
phase and
amount of
movement
–16.00 to +16.00
c)
–64.00 to +64.00
d)
4 Speed V
b)
Ver tical
direction and
speed of
waves
–100.00 to +100.00
5 Slant Slant of
waves
–8.000 to +8.000
Knob Parameter Adjustment Setting values
1 Amp H Amplitude of
waves
0.00 to 100.00
2 Freq H Frequency of
waves
0.00 to 100.00
3 Offset H
a)
Direction in
which to
offset wave
phase and
amount of
movement
–16.00 to +16.00
c)
–64.00 to +64.00
d)
4 Speed H
b)
Direction and
speed of
waves
–100.00 to +100.00
5 Slant Slant of
waves
–8.000 to +8.000
Parameter group [2/2]
Knob Parameter Adjustment Setting values
Offset
Amp
Knob Parameter Adjustment Setting values
1 Form H Waveform in
horizontal
direction
1 to 6
a)
2 Form V Waveform in
vertical direction
1 to 6
a)
Knob Parameter Adjustment Setting values
1 Form H Waveform 1 to 6
a)
Knob Parameter Adjustment Setting values
1 Random H Degree of
randomness
in horizontal
waveform
modulation
0.00 to 100.00
2 Random V Degree of
randomness
in vertical
waveform
modulation
0.00 to 100.00
3 Random
All
Degree of
randomness
in both
vertical and
horizontal
directions
Random H value
shown
Knob Parameter Adjustment Setting values
1 Random H Degree of
randomness
in waveform
modulation
0.00 to 100.00
