Global Effect Operations
Chapter 11 DME Operations
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
4
Specify the way to insert the side images when the
height is changed by pressing one of the following
buttons in the <Side V> group or the <Side H> group.
Crop: Crop the parts that do not fit into the side
without shrinking the picture. You can set the
following parameters.
The valid ranges of the parameter values depend
on the combination of signal format (SD/HD) and
aspect ratio (4:3/16:9) selected in the system, as
follows.
•4:3 mode
• 16:9 mode
The set position becomes the upper left corner of Side
V or Side H. The right and bottom sides of the inserted
image are set automatically.
Compress: Images are inserted after being
compressed. You can set the following
parameters.
The valid ranges of the parameter values depend
on the combination of signal format (SD/HD) and
aspect ratio (4:3/16:9) selected in the system, as
follows.
•4:3 mode
• 16:9 mode
The part of the image defined by Top, Left, Right, and
Bottom is magnified or shrunk to fit into Side V or
Side H.
To invert the image in a side face
For example, to invert the image on the front of Side H in
the <Side H Front> group, press the following buttons,
turning them on.
Invert H: To invert horizontally.
Invert V: To invert vertically.
For the images on the other faces, use a similar operation
in the following
groups:
• Back image of Side H: <Side H Back> group
• Front image of Side V: <Side V Front> group
• Back image of Side V: <Side V Back> group
Knob Parameter Adjustment Setting values
1 H Position of
left crop
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
2 V Position of
top crop
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
3 Rotation Angle of
rotation,
when rotated
around the
Z-axis of the
source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 H Position of
left crop
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
2 V Position of
top crop
–2.25 to +2.25(SD)
–9.00 to +9.00 (HD)
3 Rotation Angle of
rotation,
when rotated
around the
Z-axis of the
source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 Top Position of
top crop
–2.83 to +3.00 (SD)
–8.50 to +9.00 (HD)
2 Left Position of
left crop
–4.00 to +3.83 (SD)
–12.00 to +11.50
(HD)
3 Right Position of
right crop
–3.83 to +4.00 (SD)
–11.50 to +12.00
(HD)
4 Bottom Position of
bottom crop
–3.00 to +2.83 (SD)
–9.00 to +8.50 (HD)
5 Rotation Angle of
rotation,
when rotated
around the
Z-axis of the
source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 Top Position of
top crop
–2.12 to +2.25 (SD)
–8.50 to +9.00 (HD)
2 Left Position of
left crop
–4.00 to +3.87 (SD)
–16.00 to +15.50
(HD)
3 Right Position of
right crop
–3.87 to +4.00 (SD)
–15.50 to +16.00
(HD)
4 Bottom Position of
bottom crop
–2.25 to +2.12 (SD)
–9.00 to +8.50 (HD)
5 Rotation Angle of
rotation,
when rotated
around the
Z-axis of the
source
space
0/90/180/270°
