Names and Functions of Parts of the Control Panel
Chapter 2 Menus and Control Panel
d Duration setting buttons
The following buttons are used to set the duration of a
keyframe.
e KF LOOP (keyframe loop) button
Press this button, turning it on, to execute the effect the
specified number of times through the keyframes in the
specified range.
f PAUSE button
When this button is pressed, a pause is applied to the
selected keyframe.
When editing a macro, press this button, turning it on, to
include a pause event in the macro. The pause length can
be set in the numeric keypad control block.
g Effect execution section
This section is used to execute an effect, and check the
progress of the effect execution.
h Effect execution direction selection buttons
The following buttons are used to set the direction of effect
execution.
MOD
(modify)
• When this button is pressed, the selected
keyframe is modified with the values of the
current keyframe.
• When the edit point is between two
keyframes, the immediately preceding
keyframe is modified.
• You can also select multiple keyframes, and
modify them in a single operation.
• At this time, pressing this button while
holding down the [SHIFT] button in the
device control block modifies all selected
keyframes with the changed values taken
as relative values.
• During macro editing, pressing this button
amends the selected event.
• You can also select multiple events, and edit
them in a single operation.
DEL
(delete)
• When this button is pressed, the selected
keyframe is deleted.
• When the edit point is between two
keyframes, the immediately preceding
keyframe is deleted.
• During macro editing, pressing this button
deletes the selected event.
• You can also select multiple keyframes or
macro events, and delete them in a single
operation.
COPY • When this button is pressed, the selected
keyframe (during macro editing, macro
event) is copied.
• You can also select multiple keyframes or
macro events, and copy them in a single
operation.
PASTE • When this button is pressed, the deleted or
copied keyframe (during macro editing,
macro event) is inserted after the current
keyframe (during macro editing, macro
event).
• Pressing this button while holding down the
[SHIFT] button in the device control block
inserts the deleted or copied keyframe
(during macro editing, macro event) before
the current keyframe (during macro editing,
macro event).
UNDO When this button is pressed, the last executed
keyframe (during macro editing, macro event)
insertion, modification, or deletion, or paste
operation is canceled.
Name Description
Name Description
KF DUR
(keyframe
duration)
Press this button, turning it on, to set the
keyframe duration of the selected keyframe,
by numeric value entry from the numeric
keypad control block.
EFF DUR
(effect
duration)
Press this button, turning it on, to set the
effect duration from the numeric keypad
control block.
DELAY Press this button, turning it on, to enter a
delay value from the numeric keypad control
block.
CONST
DUR
(constant
duration)
• Select the duration mode.
• When this is lit, the mode is constant
duration mode, and when off, variable
duration mode.
Name Description
RUN button • When this button is pressed, the effect is
run from the first keyframe to the last
keyframe. However, if a pause is set on a
keyframe, the effect stops at that point.
• Press this button again to resume
execution, and continue to the next pause
point or the end of the effect.
REWIND
button
When this button is pressed, the currently
recalled effect is rewound to the first
keyframe.
