402
Path Setting
Chapter 13 Keyframe Effects
Changing the path type for Curve
1
In the Path menu, press [M/E-1].
The M/E-1 menu appears.
2
Press the Curve path type indication for the Key1 item
that you want to change.
A path selection window appears.
3
Press the indication for the desired path type, to select
it.
OFF: Executing the effect causes no change.
Step: There is no interpolation between
keyframes, so that the effect parameters are
updated each time a keyframe is passed.
Linear: Linear interpolation between
keyframes, resulting in constant speed movement.
S-Curve: The rate of change accelerates and
decelerates before and after a keyframe, so that the
rate of change is maximum midway between two
keyframes.
Spline: The effect follows a smooth curved path
from each keyframe to the next.
The status area reflects the selected path type.
At this point, depending on the setting for Curve, the
effect for Hue and Xpt is also affected as shown in the
following table. In the menu, the Hue and Xpt settings
do not change, but the path type indication is dimmed
out.
4
If you selected Spline as the path type, set the
following parameters, using the knobs.
Changing the path type for Hue
1
Press the Hue path type indication for the item that you
want to change.
2
Turn knob 1 to change the Hue path type.
The path type indications shown in the menu represent
the change in hue as seen on a Vectorscope.
CW: Rotate clockwise.
CCW: Rotate counterclockwise.
Short: The hue changes in whichever of the
clockwise and counterclockwise directions is
shorter.
Long: The hue changes in whichever of the
clockwise and counterclockwise directions is
longer.
Changing the path type for Xpt
1
Press the Xpt path type indication for the item that you
want to change.
A path selection window appears.
2
Press the indication for the desired path type, to select
it.
Xpt Hold off: When replaying a keyframe,
change the inputs to the settings saved in memory.
Xpt Hold on: When replaying a keyframe, do
not change the inputs.
Curve
setting
Hue change Xpt change
OFF Does not change Hold
Step Changes as with the Step
setting
Is not affected
Knob Parameter Adjustment Setting
values
1 Tens Spline interpolation
tension
–4.00 to
+4.00
2 Bias Spline interpolation
bias
–4.00 to
+4.00
3 Cont Spline interpolation
continuity
–4.00 to
+4.00
To Next Page
