Cross-Point Settings (Xpt Assign Menu)
Chapter 19 Control Panel Setup (Panel)
5
Using the buttons in the <Xpt Assign> group, assign
the selected signal to the button number currently
selected in the main table.
Set: Delete the signal currently assigned to the
selected button number and make a new
assignment.
Insert: Move down one line the signal currently
assigned to the selected button number and
following signals, and make a new assignment.
When a button number upper than 121 is selected,
execution of “Insert” is impossible. The signal
assignments to button numbers upper than 121 cannot
be changed. When “Insert” is executed for any other
number, moving down of signals ends at number 120,
and the signals assigned to numbers upper than 121 are
maintained in their original lines.
To disable a button
In the Panel >Xpt Assign >Main, V/K Pair Assign menu,
select the button you want to disable, and press [Inhibit].
To delete any currently assigned signal
In the Panel >Xpt Assign >Main, V/K Pair Assign menu,
select the button corresponding to the signal you want to
delete, and press [Delete] in the <Xpt Assign> group.
Signal deletion is executed in accordance with the
selection in the <Assign> group, and the signal assigned to
the button number next to the selected button number and
following signals move up one line.
When a button number upper than 121 is selected,
execution of “Delete” is impossible. The signal
assignments to button numbers upper than 121 cannot be
changed. When a signal assigned to any other button
number is deleted, moving up of signals ends when the
signal assigned to number 120 has moved to number 119,
and the signals assigned to numbers upper than 121 are
maintained in their original lines.
Creating tables 1 to 14
When creating tables 1 to 14, in the same way as when
creating the main table, you can assign the same signal to
more than one button number, or delete currently assigned
signals. However, assignment of video and key
combinations is impossible.
1
In the Panel >Xpt Assign menu, press [Table Button
Assign].
The Table Button Assign menu appears.
The table number appears on the upper left part of the
status area.
The left part of the status area shows the cross-point
button numbers, video and key pair numbers, video
signal source names and source numbers, and key
signal source names and source numbers. When the
shift button is pressed, the number column is
distinguished by color.
The right part shows the video and key pair numbers,
and the names of video signals and key signals set in
the main table.
The Table Button Assign menu also allows you to
access the Main, V/K Pair Assign menu and the Src
Name/LCD Color menu.
2
Using the knob, select the table number.
3
Using any of the following methods, select the button
number.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
4
Using any of the following methods, select the pair
number.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
5
Using the buttons in the <Button Assign> group,
assign the selected pair number to the button number
currently selected in table 1.
Set: Delete the signal currently assigned to the
selected button number and make a new
assignment.
Insert: Move down one line the signal currently
assigned to the selected button number and
following signals, and make a new assignment.
When a button number upper than 121 is selected,
execution of “Insert” is impossible. The signal
Notes
Notes
Knob Parameter Adjustment Setting values
1 Ta b l e N o Selection of the
table to be set
1 to 14
Knob Parameter Adjustment Setting values
2 Button No Cross-point button
selection
1 to 300
Knob Parameter Adjustment Setting values
3 V/K Pair
No
Selection of video
and key pair
number to be
assigned
1 to 300
Notes
