590
Data Saved by [Setup Define] and [Initial Status Define]
Appendix (Volume 2)
Included in Switcher Setup
7324.1 Engineering Setup >Panel >Prefs/Utility >Utility
Module Assign
All data relating to function assignment to utility/
shotbox control block
7324.2 Engineering Setup >Panel >Prefs/Utility >Key 2/4
Bus Button Assign
All data relating to utility/shotbox assignment to
cross-point buttons in the key 2 row
7325 Engineering Setup >Panel >Device Interface All data relating to Device Interface menu
7325.1 Engineering Setup >Panel >Device Interface >GPI
Input
All data relating to GPI Input menu
7325.3 Engineering Setup >Panel >Device Interface >GPI
Output
All data relating to GPI Output menu
7325.4 Engineering Setup >Panel >Device Interface >DCU
Serial Port/MPE Assign
All data relating to DCU Serial Port/MPE Assign
menu
7326 Engineering Setup >Panel >Operation All data relating to Operation menu
7326.2 Engineering Setup >Panel >Operation >Effect Mode All data relating to Effect Mode menu (excluding
[Default KF Duration] setting values)
7326.3 Engineering Setup >Panel >Operation >Flexi Pad
Mode
All data relating to Flexi Pad Mode menu
7326.4 Engineering Setup >Panel >Operation >Custom
Button
All data relating to Custom Button menu
7326.5 Engineering Setup >Panel >Operation >Sensitivity All data relating to Sensitivity menu
7326.6 Engineering Setup >Panel >Operation >Macro All data relating to Macro menu
7326.9 Engineering Setup >Panel >Operation >ButtonTally All data relating to ButtonTally menu
7326.12 Engineering Setup >Panel >Operation >Key Row
Operation
All data relating to Key Row Operation menu
7327 Engineering Setup >Panel >Maintenance • Setting data for the following buttons:
- [Screen Saver]
- [LCD Brightness]
- [LED Brightness]
- [Switch Brightness]
- [Touch Beep]
• Setting data for Initial Menu
7351 to 7355 Engineering Setup >DCU All data relating to DCU
7361 to 7367 Engineering Setup >Router/Tally All data relating to router interface and tally interface
7371 to 7373 Engineering Setup >MPE All data relating to MPE
— — Data of Color Palette window
Menu number Menu path Saved data
Menu number Menu path Saved data
3221 Misc >Safe Title All data relating to Safe Title menu
7322.5 Engineering Setup >Panel >Xpt Assign >Main,V/K
Pair Assign
Cross-point assignment settings (excluding <Xpt
Shift Mode> and <Display Shift Mode> groups)
7322.6 Engineering Setup >Panel >Xpt Assign >Src Name/
LCD Color
• Names of source signals
• Color of source name display for each source
signal
7326.2 Engineering Setup >Panel >Operation >Effect Mode Setting of [Default KF Duration] for switcher
keyframes
7331
7331.1
7331.2
7331.3
• Engineering Setup >Switcher >Config
• Engineering Setup >Switcher >Config >M/E
Output Assign
• Engineering Setup >Switcher >Config >PGM
Config
• Engineering Setup >Switcher >Config >K-PVW
Config
• All data relating to Config menu
• All data relating to M/E Output Assign menu
• All data relating to PGM Config menu
• All data relating to K-PVW Config menu
To Next Page
