Sony MVS-7000X - Page 593

593
Data Saved by [Setup Define] and [Initial Status Define]
Appendix (Volume 2)
Included in Switcher (Same as data saved in Snapshots)
In Multi Program 2 mode, M/E Config settings are saved
in a snapshot when [Recall M/E Config] is set to ON, but
are not saved by [Initial Status Define].
Included in DME
Notes
Menu number Menu path Saved data
— — • For each M/E, setting data relating to the following:
cross-points, transitions, Key1 to Key8 (including
settings in the independent key transition control block),
wipes, DME wipes, video processing
• Color backgrounds 1/2
• Frame memory
• AUX bus (including video processing settings)
3211 Misc >Enable >Port Enable Setting data for <Switcher> group
3213 Misc >Enable >Side Flags All data relating to Side Flags menu
Menu number Menu path Saved data
3211 Misc >Enable >Port Enable <DME1> and <DME2> group data
4100 DME >Status Three-dimensional transformation data
4111 DME >Edge >Border/Crop All data relating to Border/Crop menu
4112 DME >Edge >Beveled Edge All data relating to Beveled Edge menu
4121 to 4124 DME >Video Modify All data relating to Video Modify menu
4131 DME >Freeze >Freeze All data relating to Freeze menu
4141 (4141.1 to
4141.28)
DME >Non Linear All data relating to Non Linear menu
4151 DME >Light/Trail >Lighting All data relating to Lighting menu
4152 DME >Light/Trail >Trail All data relating to Trail menu
4153 DME >Light/Trail >Motion Decay All data relating to Motion Decay menu
4154 DME >Light/Trail >KF Strobe All data relating to KF Strobe menu
4161 DME >Input/Output >Bkgd All data relating to Bkgd menu
4162 DME >Input/Output >Video/Key All data relating to Video/Key menu
4163 DME >Input/Output >Process All data relating to Process menu
4164 DME >Input/Output >Graphic All data relating to Graphic menu
4211, 4221 Global Effect >Ch1-Ch4 >Combine Priority
Global Effect >Ch5-Ch8 >Combine Priority
All data relating to Combine Priority menu
4212, 4222 Global Effect >Ch1-Ch4 >Brick
Global Effect >Ch5-Ch8 >Brick
All data relating to Brick menu
4213, 4223 Global Effect >Ch1-Ch4 >Shadow
Global Effect >Ch5-Ch8 >Shadow
All data relating to Shadow menu
4113 DME >Edge >Key Border All data relating to Key Border menu
4114 DME >Edge >Art Edge All data relating to Art Edge menu
4115 DME >Edge >Flex Shadow All data relating to Flex Shadow menu
4116 DME >Edge >Wipe Crop All data relating to Wipe Crop menu
4117 DME >Edge >Color Mix All data relating to Color Mix menu
4127 DME >Video Modify >Mask All data relating to Mask menu
4155 DME >Light/Trail >Wind All data relating to Wind menu
