Chapter 2 Preparing for Service 2-7
FIGURE 2-2 Locating the Metal Lever
Caution – The server weighs approximately 40 lb (18 kg). The next step requires two
people to dismount and carry the chassis.
5. From the front of the server, pull the release tabs forward and pull the server
forward until it is free of the rack rails.
The release tabs are located on each rail, about midway on the server.
6. Set the server on a sturdy work surface.
7. Perform antistatic measures.
See Section 2.3.4, “Performing Antistatic Measures” on page 2-8.
