2-14 Sun Netra T5220 Server Service Manual • January 2012
14
Motherboard
assembly
Section 4.10, “Replacing the
Motherboard Assembly” on
page 4-36
Must be removed before removing the
power distribution board.
MB
15
PCI riser
assembly
Section 4.2.4, “Replacing the
Lower PCIe/XAUI Cards”
on page 4-11
Houses and connects the bottom PCI cards
16
PCI mezzanine Section 2.3.6, “Removing the
PCI Mezzanine” on page 2-9
Houses and connects the top PCI cards PCI_MEZZ
17
PCI-X cards Section 4.2.2, “Replacing
PCI-X 4 and PCIe 5 Cards”
on page 4-5
Optional add-on cards PCI-X4
PCI-X3
18
PCIe cards Section 4.2.4, “Replacing the
Lower PCIe/XAUI Cards”
on page 4-11
Optional add-on cards PCIE0/XAUI0
PCIE1/XAUI1
PCIE2, PCIE5
19
FB-DIMMs Section 4.6, “Replacing
FB-DIMMs” on page 4-23
Can be ordered in the following sizes:
• 1 GB (16 GB maximum)
• 2 GB (32 GB maximum)
• 4 GB (64 GB maximum)
See
FIGURE 4-15
and TABLE 4-1
* The FRU name is used in system messages.
TABLE 2-1
Server FRU List (Continued)
No. FRU Replacement Instructions Description FRU Name
*
