3-4 Sun Netra T5220 Server Service Manual • January 2012
FIGURE 3-4 Opening Hard Drive Latch
Caution – The latch is not an ejector. Do not bend it too far to the left. Doing so can
damage the latch.
5. Grasp the latch and pull the drive out of the drive slot (
FIGURE 3-5).
Figure Legend
1 Latch release button
2 Latch
