124 Sun Server X4-2 Service Manual • May 2014
6. Reconnect the SAS cable to the disk backplane [6].
7. If the server has more than four storage drives, repeat all of the preceding steps
(with the exception of Step 3, which directs you to reconnect the DVD drive
power cable) to install the second disk backplane.
A server that has two disk backplanes does not have a DVD drive installed.
8. Reinstall all of the storage drives into the storage drive cage.
See “Install a Storage Drive” on page 49.
9. Install all four fan modules.
See “Install a Fan Module” on page 54.
10. Return the server to operation.
a. Close the server fan door.
b. Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 148.
c. Reconnect the data cables to the server and reconnect the power cords to the
server power supplies.
See “Reconnect Data Cables and Power Cords” on page 149.
d. Power on the server.
See “Power On the Server” on page 150.
Verify that the Power/OK status indicator is steady on.
Note – IMPORTANT: After replacing disk backplane 0 (DBP0), you must manually
program the product serial number (PSN) into the new disk backplane. This is
necessary because DBP0 is the primary member of a select group of components for
maintaining the PSN for service entitlement. On systems with two disk backplanes,
disk backplane 1 (DBP1) does not have this requirement. To propagate the FRU
top-level indicator (TLI) data to the new DBP0, you must reset the Oracle ILOM
service processor (SP). For instructions on resetting the SP, see the Oracle Integrated
Lights Out Manager (ILOM) 3.1 Configuration and Maintenance Guide at
http://www.oracle.com/goto/ILOM/docs
Related Information
■ “Remove the Disk Backplane” on page 119
