Servicing FRUs 129
b. Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 39.
c. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 42.
d. Remove the server top cover.
See “Remove the Server Top Cover” on page 43.
2. Remove the following reusable components:
Caution – During the motherboard removal procedure, it is important to label the
power supplies with the slot numbers from which they were removed (PS0, PS1).
This is required because the power supplies must be reinstalled into the same slots
from which they were removed; otherwise, the server FRU top-level indicator (TLI)
data might be lost. When a server requires service, the FRU TLI is used by Oracle to
verify that the warranty on the server has not expired. For more information on the
server FRU TLI, see “FRU TLI Auto-Update” on page 30.
a. Fan modules
For instructions, see “Remove a Fan Module” on page 51.
b. Power supplies
For instructions, see “Remove a Power Supply” on page 57.
c. PCIe risers and attached PCIe cards
For instructions, see “Servicing PCIe Risers (CRU)” on page 74.
3. Disconnect the disk backplane power cable from the motherboard [1].
