Servicing FRUs 137
c. Place the FIM cable and the disk backplane power cable alongside the
mid-wall next to their respective motherboard connectors.
d. Ensure that FIM cable and the disk backplane power cable are not pinched
by the mid-wall and that they run beside the mid-wall and not under it;
otherwise, the cables might be damaged.
e. To secure the mid-wall to the server chassis, tighten the four green captive
screws.
4. Carefully place the SAS cable(s) that you disconnected from the internal HBA
into the cable trough provided by the air duct on the motherboard.
5. If the server has a DVD drive, carefully place the DVD drive cable into the
cable trough provided by the air duct on the motherboard.
6. If the server has a DVD drive, reconnect the DVD drive cable to the
motherboard [3].
7. Reconnect the front indicator module (FIM) cable to the motherboard [4].
8. Reconnect the disk backplane LED cable to the motherboard [5].
9. Reconnect the disk backplane power cable to the motherboard [6].
10. Reinstall the following reusable components:
a. PCIe risers and attached PCIe cards
For instructions, see “Servicing PCIe Risers (CRU)” on page 74.
b. Power supplies
Caution – When reinstalling power supplies, it is important to reinstall them into
the slots from which they were removed during the motherboard removal procedure;
otherwise, the server FRU top-level indicator (TLI) data might be lost. When a server
requires service, the FRU TLI is used by Oracle to verify that the warranty on the
server has not expired. For more information on the server FRU TLI, see “FRU TLI
Auto-Update” on page 30.
For instructions, see “Install a Power Supply” on page 59.
c. Fan modules
For instructions, see “Install a Fan Module” on page 54.
11. Return the server to operation.
a. Install the server top cover.
See “Install the Server Top Cover” on page 145.
