SWF Dual Function E Series User Manual


7
Troubleshooting
7.1.0 Error displays and troubleshooting
7.1.1 Main shaft motor and others
7.1.2 X,Y motors
100 Wrong position of main shaft stop Main shaft didn’t stop at 100°
Use a lever to adjust the shaft
angle at 100°
103 Trimmer sensor return failure
Trimming sensor does not return
after trimming
Check the trimming unit.
104 Error in start switch
START is pressed when the
power is turned on
Check if START touches the
connector
105 Error in stop switch
STOP is pressed when the power
is turned on
Check if STOP touches the
connector
108 Air pressure error
Error occurs when air pressure is
below the threshold(Sequin)
110 AC Line error
This error occurs when the joint
board has problems
Replace the joint board
102 Main shaft overload
Thread tangle around hook,
Needle controller malfunction,
Thread tangle when trimming
Check the hooks on all heads and
turn the main switch OFF and ON
again.
101 Error in main shaft motor driver Error in main shaft motor driver Turn the main switch OFF and ON again.
No. ERROR TYPE ERROR CORRECTION
107 Valve failure Error occurs when valve opens
200 +X limit detection failure
Frame reached ＋X limit.
Move the frame in the －X
direction.
201 -X limit detection failure
Frame reached －X limit.
Move the frame in the ＋X
direction.
202 +Y limit detection failure
Frame reached ＋Y limit.
Move the frame in the －Y
direction.
203 -Y limit detection failure
Frame reached －Y limit.
Move the frame in the ＋Y
direction.
204 Error in X-axis driver Error in X-axis driver
Turn main switch OFF and ON
again
205 Error in Y-axis driver Error in Y-axis driver
Turn main switch OFF and ON
again
No. ERROR TYPE ERROR CORRECTION
206 Wiper return failure Wiper motor does not return Repair wiper mechanism
207 Error in trimmer return Trimmer solenoid does not return Repair trimmer mechanism
