SWF Dual Function E Series User Manual


7.1.3 Needle(color) change
7.1.4 Encoder
7.1.5 Repeat
300 Needle position error
Needle does not come to the
correct position when changed
Manually turn the needle bar,
check the load, and locate it in the
right position.
No. ERROR TYPE ERROR CORRECTION
501 Error in repeat setting
Off the repeat setting limit
(X repeat×Y repeat >99)
Adjust the repeat setting so that
X repeat×Y repeat <99
No. ERROR TYPE ERROR CORRECTION
400 Error in A of main shaft encoder
Error in A signal of the main
shaft encoder.
Check cable connection. Turn the
main power OFF and ON again.
401 Error in Z of main shaft encoder
Error in Z signal of the main
shaft encoder.
Check cable connection. Turn the
main power OFF and ON again.
No. ERROR TYPE ERROR CORRECTION
