SWF Dual Function E Series - Advanced Settings and Troubleshooting; 5.9 General Settings


[Fig.5.9.0-1]
󱅀 Basic setting : For setting parameters such as scale up, scale down, and angle.
󱅀 EMB parameter setting : For setting parameters related to embroidery.
󱅀 M/C parameter setting : For setting parameters related to the machine.
󱅀 Needle setting : For setting or changing the needle bar.
󱅀 Frame offset setting : For setting offset point on the design.
󱅀 Option setting : For setting design method of sequin, cording etc.
󱅀 The others setting : For setting needle type and thread detection
5.9.0 Setting
- This function is for general setting of the embroidery. You have seven menus → basic setting, EMB
parameter setting, M/C parameter setting, needle setting, frame offset setting, option setting, and the
others setting.
Select in the initial screen and you will see [Fig.5.9.0-1]
