SWF Dual Function E Series User Manual


7.3.2 I/O Board , X/Y Driver Board Dip Switch Setting
As in <Fig. 7.3.1-1>, the locations of board and driver can be checked from the rear side of Control Box.
(1) I/O Board's Dip Switch Setting
- Switch Location on I/O Board
- Dip Switch (SW1) Setting
The upper board is MC1, and there is no need to make particular setting for I/O Board.
Dip Switch
CN4
CN1
CN3 SW1
ON
OFF
1234
Functions OFF ON
Reserved
Reserved
Reserved
Reserved
-
-
-
-
-
-
-
-
