SWF Dual Function E Series User Manual


7.3.0 Machine Setting and Troubleshooting (
※※
In case of Dual Function 2
××
2 or above)
7.3.1 Rear Side of Control Box
<Fig. 7.3.1-1> is the rear side of Control Box.
① MC1 Main Driver
② MC1 XY Driver
③ MC2 XY Driver
④ MC2 Main Driver
⑤ IO Ass'y
⑥ LAMP Ass'y
[Fig.7.3.1-1]
 MC1(L)
Main Driver
 IO Ass'y
 LAMP Ass'y
 MC1(L)
XY Driver
 MC2(R)
XY Driver
 MC2(R)
Main Driver
